Insulation wall panels are centered on precision manufacturing and rely on fully automated production lines to achieve standardized production. High-density polyurethane core material is selected and formed through high-pressure continuous foaming process, ensuring that the closed-cell rate of the core material is over 95%, and it has excellent thermal insulation and waterproof performance. The panel and core material are made through a hot-pressing composite process. Through precise temperature control and pressure regulation, a tight bond is achieved, eliminating the risk of delamination and peeling.
The production process integrates numerical control cutting technology, with dimensional errors controlled within ±0.5mm, meeting the construction requirements of various types of buildings. The surface is treated with an anti-scratch and wear-resistant coating, which takes into account both decorative and durable properties. The entire process adheres to the GB/T 20284 standard and undergoes multiple quality inspections to ensure that each wall panel possesses core advantages such as B1-level flame retardancy and low thermal conductivity, highlighting exquisite craftsmanship and reliable quality.
| Comparison Dimension | Our Insulation Wall Panels Advantages | Industry Peers' Common Situation |
|---|---|---|
| Production Process | Full automatic foaming + CNC compounding, dimensional error ±0.5mm, high stability | Semi-automatic production, dimensional error ±2mm, prone to bonding issues |
| Core Material | High-density polyurethane core (≥40kg/m³), closed-cell rate 95%+, Class B1 flame retardant | Ordinary core (≤30kg/m³), closed-cell rate below 85%, some Class B2 flame retardant |
| Product Structure | Integration of insulation, decoration and waterproofing, no additional treatment required | Only meets basic insulation needs, separate waterproofing and decoration required |
| Quality Control | Compliant with GB/T 20284 + ISO 9001, 12 full inspections, 100% qualification rate | Only meets basic standards, incomplete inspection items, occasional quality risks |
| Construction & Service | Customization available, with dedicated accessories, high construction efficiency, 5-year warranty | Single specification, construction relies on on-site cutting, 1-2 year warranty, limited technical support |
Thermal insulation wall panels, with their core advantages of thermal insulation, heat preservation, flame retardancy, waterproofing and decoration integration, are widely adapted to various building scenarios.
